TLV3012AIDBVR IC COMPARATOR 1 W/VOLT REF SOT23 Voltage Reference Push-Pull

Brand Name : Original

Model Number : TLV3012AIDBVR

Certification : Original

Place of Origin : Original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Voltage - Supply, Single/Dual (±) : 1.8V ~ 5.5V

Voltage - Input Offset (Max) : 12mV @ 5.5V

Current - Input Bias (Max) : 10pA @ 5.5V

Current - Quiescent (Max) : 5µA

Propagation Delay (Max) : 13.5µs

Supplier Device Package : SOT-23-6

Contact Now

TLV3012AIDBVR IC COMPARATOR 1 W/VOLT REF SOT23 Voltage Reference Push-Pull

Features

LOW QUIESCENT CURRENT: 5µA (max)
● INTEGRATED VOLTAGE REFERENCE: 1.242V
● INPUT COMMON-MODE RANGE:
200mV Beyond Rails
● VOLTAGE REFERENCE INITIAL ACCURACY: 1%
● OPEN-DRAIN LOGIC COMPATIBLE OUTPUT:
TLV3011
● PUSH-PULL OUTPUT: TLV3012
● LOW-SUPPLY VOLTAGE: 1.8V to 5.5V
● FAST RESPONSE TIME: 6µs Propagation Delay
with 100mV Overdrive (TLV3011: RPULL-UP = 10kΩ)
● MicroSIZE PACKAGES: SOT23-6 and SC70-6

Product Attributes
Type
with Voltage Reference
Number of Elements
1
Output Type
Push-Pull
Voltage - Supply, Single/Dual (±)
1.8V ~ 5.5V
Voltage - Input Offset (Max)
12mV @ 5.5V
Current - Input Bias (Max)
10pA @ 5.5V
Current - Output (Typ)
-
Current - Quiescent (Max)
5µA
CMRR, PSRR (Typ)
74dB CMRR, 80dB PSRR
Propagation Delay (Max)
13.5µs
Hysteresis
-
Operating Temperature
-40°C ~ 85°C
Package / Case
SOT-23-6
Mounting Type
Surface Mount
Supplier Device Package
SOT-23-6
Base Product Number
TLV3012

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001


Applications

● BATTERY-POWERED LEVEL DETECTION
● DATA ACQUISITION
● SYSTEM MONITORING
● OSCILLATORS
● SENSOR SYSTEMS:
Smoke Detectors, Light Sensors, Alarms
